モデル　 ANT-BHA-2-18
Material Aluminum
Frequency Range 2.0 – 18.0 GHz
Peak Gain 15 dBi
Polarization Dual linear
Port-to-port Isolation 25 dB
Cross-polar Discrimination 20 dB
VSWR 1.8:1 typical, 2.5:1 peak
RF Connector (50 Ω) 2 x 2.92 mm
Max Power 25 W

モデル　ANT-BHA-1-15
Material Aluminum
Frequency Range 1.0 – 15.0 GHz
Peak Gain 13 dBi
Polarization Dual Linear
Port-to-port Isolation 25 dB
Cross-polar Discrimination 20 dB
VSWR 1.8:1 typical, 2.5:1 peak
RF Connector (50 Ω) Type-N female
Max Power 50 W

モデル ANT-BHA-1-18
Material Aluminum
Frequency Range 1.0 – 18.0 GHz
Peak Gain 13 dBi
Polarization Dual Linear
Port-to-port Isolation 25 dB
Cross-polar Discrimination 20 dB
VSWR 1.8:1 typical, 2.5:1 peak
RF Connector (50 Ω) Type-N female
Max Power 50 W
